Scope of Work:

Concrete shop drawings are detailed technical drawings that provide precise information about the construction and installation of concrete elements within a project. They are typically created by a structural engineer or a specialized drafting team and serve as a crucial reference for contractors, fabricators,and construction teams
The purpose of concrete shop drawings is to translate the design intent and specifications provided by structural engineers into actionable plans and instructions for the construction process. These drawings include comprehensive information about the dimensions, materials, reinforcement, and connections of concrete elements.
